FPS S Series 100-200 Spares

FPS S Series 100-200 spares
18 original spare parts for the FPS SF 100-200 bareshaft end suction pump: impeller, cast iron volute, wear rings, shaft and sleeves, bearing frame and bearings, mechanical seal and gland packing kits and small parts.
| Pump | FPS SF 100-200 (bareshaft) |
| Parts | 18 |
| Hydraulic parts | impeller, volute, wear rings |
| Sealing | mechanical seal kit, gland packing kit, O-ring |
How to choose: check the part number against your pump before ordering; send us a photo of the nameplate if unsure.
| Complete Specifications, Sizing and Price Guide – Click Here |
- FPS S-Series Volute O-Ring – R3OR031
R 172.50The FPS S-Series Volute O-Ring - R3OR031 is a replacement volute o-ring for the FPS SF 32-200, SF 40-200, SF 50-200, SF 65-200, SF 80-200, SF 100-200 pump.SpecificationsBrandFPSItem codeR3OR031PartVolute O-RingFitsSF 32-200, SF 40-200, SF 50-200, SF 65-200, SF 80-200, SF ... - FPS S-Series Magnetic Drain Plug – 3NO284
R 226.40The FPS S-Series Magnetic Drain Plug - 3NO284 is a replacement magnetic drain plug for the FPS SF 32-160, SF 32-200, SF 40-160, SF 40-200, SF 40-250, SF 50-160, SF 50-200, SF 50-250, SF 65-160, SF 65-200, SF 65-250, SF ... - FPS S-Series Bearing Frame – KSNFCU3OB/A
R 18,554.53The FPS S-Series Bearing Frame - KSNFCU3OB/A is a replacement bearing frame for the FPS SF 65-250, SF 80-200, SF 80-250, SF 80-315, SF 100-200, SF 100-250, SF 100-315, SF 125-250 pump.SpecificationsBrandFPSItem codeKSNFCU3OB/APartBearing FrameFitsSF 65-250, SF 80-200, SF 80-250, SF ... - FPS S-Series Oil Plug – 3NO271
R 107.81The FPS S-Series Oil Plug - 3NO271 is a replacement oil plug for the FPS SF 32-160, SF 32-200, SF 40-160, SF 40-200, SF 40-250, SF 50-160, SF 50-200, SF 50-250, SF 65-160, SF 65-200, SF 65-250, SF 80-160, SF ... - FPS S-Series Back Cover (Gland Seal Plate) – KSNESC5
R 2,490.46The FPS S-Series Back Cover (Gland Seal Plate) - KSNESC5 is a replacement back cover (gland seal plate) for the FPS SF 80-200, SF 100-200 pump.SpecificationsBrandFPSItem codeKSNESC5PartBack Cover (Gland Seal Plate)FitsSF 80-200, SF 100-200ApplicationsService and repair of FPS S-Series pumpsFeaturesGenuine ... - FPS S-Series Protection Cover Kit – 830017582
R 927.18The FPS S-Series Protection Cover Kit - 830017582 is a replacement protection cover kit for the FPS SF 65-250, SF 80-200, SF 80-250, SF 80-315, SF 100-200, SF 100-250, SF 100-315, SF 125-250 pump.SpecificationsBrandFPSItem code830017582PartProtection Cover KitFitsSF 65-250, SF 80-200, ... - FPS S-Series Gland Packing Kit – KSNETB3
R 4,075.31The FPS S-Series Gland Packing Kit - KSNETB3 is a replacement gland packing kit for the FPS SF 65-250, SF 80-200, SF 80-250, SF 80-315, SF 100-200, SF 100-250, SF 100-315, SF 125-250 pump.SpecificationsBrandFPSItem codeKSNETB3PartGland Packing KitFitsSF 65-250, SF 80-200, ... - FPS S-Series Mechanical Seal Kit – KSNETM3
R 5,735.62The FPS S-Series Mechanical Seal Kit - KSNETM3 is a replacement mechanical seal kit for the FPS SF 65-250, SF 80-200, SF 80-250, SF 80-315, SF 100-200, SF 100-250, SF 100-315, SF 125-250 pump.SpecificationsBrandFPSItem codeKSNETM3PartMechanical Seal KitFitsSF 65-250, SF 80-200, ... - FPS S-Series Shaft Protection Sleeve (Mechanical Seal Version) – 215369T
R 4,452.65The FPS S-Series Shaft Protection Sleeve (Mechanical Seal Version) - 215369T is a replacement shaft protection sleeve (mechanical seal version) for the FPS SF 65-250, SF 80-200, SF 80-250, SF 80-315, SF 100-200, SF 100-250, SF 100-315, SF 125-250 pump.SpecificationsBrandFPSItem ... - FPS S-Series Shaft Protection Sleeve (Gland Packing Version) – 216084T
R 4,452.65The FPS S-Series Shaft Protection Sleeve (Gland Packing Version) - 216084T is a replacement shaft protection sleeve (gland packing version) for the FPS SF 65-250, SF 80-200, SF 80-250, SF 80-315, SF 100-200, SF 100-250, SF 100-315, SF 125-250 pump.SpecificationsBrandFPSItem ... - FPS S-Series Gland Packing Ring – 205643F
R 517.50The FPS S-Series Gland Packing Ring - 205643F is a replacement gland packing ring for the FPS SF 65-250 (8mm ring), SF 80-200 (10mm ring), SF 80-250 (10mm ring), SF 80-315 (10mm ring), SF 100-200 (10mm ring), SF 100-250 (10mm ... - FPS S-Series Bearing – 3CU051
R 905.62The FPS S-Series Bearing - 3CU051 is a replacement bearing for the FPS SF 65-250, SF 80-200, SF 80-250, SF 80-315, SF 100-200, SF 100-250, SF 100-315, SF 125-250 pump.SpecificationsBrandFPSItem code3CU051PartBearingFitsSF 65-250, SF 80-200, SF 80-250, SF 80-315, SF 100-200, ... - FPS S-Series Volute Wear Ring – 215763A/A
R 1,035.00The FPS S-Series Volute Wear Ring - 215763A/A is a replacement volute wear ring for the FPS SF 100-200 pump.SpecificationsBrandFPSItem code215763A/APartVolute Wear RingFitsSF 100-200ApplicationsService and repair of FPS S-Series pumpsFeaturesGenuine replacement partFits SF 100-200Need help choosing or want a price?Our ... - FPS S-Series Oil Seal (Lip) – 3AT042
R 237.18The FPS S-Series Oil Seal (Lip) - 3AT042 is a replacement oil seal (lip) for the FPS SF 65-250, SF 80-200, SF 80-250, SF 80-315, SF 100-200, SF 100-250, SF 100-315, SF 125-250 pump.SpecificationsBrandFPSItem code3AT042PartOil Seal (Lip)FitsSF 65-250, SF 80-200, ... - FPS S-Series Shaft (AISI 420 Stainless Steel) – 215371T
R 12,484.68The FPS S-Series Shaft (AISI 420 Stainless Steel) - 215371T is a replacement shaft (aisi 420 stainless steel) for the FPS SF 65-250, SF 80-200, SF 80-250, SF 80-315, SF 100-200, SF 100-250, SF 100-315, SF 125-250 pump.SpecificationsBrandFPSItem code215371TPartShaft (AISI ... - FPS S-Series Sight Glass – 3NO272
R 118.59The FPS S-Series Sight Glass - 3NO272 is a replacement sight glass for the FPS SF 32-160, SF 32-200, SF 40-160, SF 40-200, SF 40-250, SF 50-160, SF 50-200, SF 50-250, SF 65-160, SF 65-200, SF 65-250, SF 80-160, SF ... - FPS S-Series Impeller (304 Stainless Steel) – 215759T00
R 9,918.75The FPS S-Series Impeller (304 Stainless Steel) - 215759T00 is a replacement impeller (304 stainless steel) for the FPS SF 100-200 pump.SpecificationsBrandFPSItem code215759T00PartImpeller (304 Stainless Steel)FitsSF 100-200ApplicationsService and repair of FPS S-Series pumpsFeaturesGenuine replacement partFits SF 100-200Need help choosing or ... - FPS S-Series Volute (Cast Iron) – KSNFCP100-200
R 7,837.96The FPS S-Series Volute (Cast Iron) - KSNFCP100-200 is a replacement volute (cast iron) for the FPS SF 100-200 pump.SpecificationsBrandFPSItem codeKSNFCP100-200PartVolute (Cast Iron)FitsSF 100-200ApplicationsService and repair of FPS S-Series pumpsFeaturesGenuine replacement partFits SF 100-200Need help choosing or want a price?Our ...
