Meudy FSM2.75F / 0.75KW 230V Submersible Dewatering Pumps
12142
The Meudy FSM2.75F is a 0.75 kW single-phase submersible drainage pump with a 50 mm outlet and built-in float switch, for building sites, basements, pits, rainwater and muddy water. It delivers 10 m³/h at 11 m head, with a maximum head of 18 m and a maximum flow of 16 m³/h.
Its semi-vortex impeller and shaft-mounted agitator reduce clogging and prevent air lock. IP68 motor, max. water depth 10 m.
At a glance
Power: 0.75 kW (1 HP)Supply: Single-phase 220 V, 50 HzMax. head: 18 mMax. flow: 16 m³/hConnections: 50 mmBest for: Civil engineering, building sites, basements or other utility, Pits, rainwater, mud water and high-viscosity fluid.Specifications
| Brand | Meudy |
| Model | FSM2.75F |
| Pump type | Submersible drainage pump with float switch |
| Motor power | 0.75 kW (1 HP) |
| Power supply | Single-phase 220 V, 50 Hz |
| Rated current (1~) | 5 A |
| Speed | 2850 rpm |
| Starting | Direct on line |
| Outlet | 50 mm |
| Rated duty | 10 m³/h @ 11 m |
| Max. flow | 16 m³/h |
| Max. head | 18 m |
| Solids passage | 6 mm |
| Max. liquid temperature | 40 °C |
| Motor protection | IP68 |
| Dimensions (W × L × H) | 26.5 × 44.5 × 25.5 cm |
| Weight | 17.5 kg |
| Item code | FSM2.75F(220V) |
Performance Table
| Flow Q (m³/h) | 0 | 5 | 10 | 12.5 | 15 | 16 |
|---|---|---|---|---|---|---|
| Head H (m) | 18 | 15.5 | 11 | 8.5 | 4 | 1.5 |
Head at each flow rate from the manufacturer's technical data. For a duty-point check use the Get a Quote wizard below.
Performance Curves and Technical Data (PDF)
Download the curve sheet with the performance curves, dimensions and technical data for the Meudy FSM2.75F:
Meudy FSM 2.75 Drainage Pump Curve
8 kB | Download
Applications
- Civil engineering, building sites, basements or other utility
- Pits, rainwater, mud water and high-viscosity fluid.
Need help choosing or want a price?
Our pump team will check the right size for your flow and head and give you a quote.
WhatsApp us: 082 516 2248 Get a Quote / Size my pump info@pumps.co.za
Frequently Asked Questions
What is the maximum head of the Meudy FSM2.75F?
The Meudy FSM2.75F has a maximum head of 18 m.
How much water can the Meudy FSM2.75F pump?
The Meudy FSM2.75F pumps up to 16 m³/h.
What power supply does the Meudy FSM2.75F need?
Supply: Single-phase 220 V, 50 Hz. Motor power: 0.75 kW (1 HP).
What are the pipe connections of the Meudy FSM2.75F?
50 mm.
