Leo Submersible Sewage Pumps 65SWE15-10-1.1 - 220V

The LEO 65SWE15-10-1.1 is a SWE submersible sewage pump with a DN65 discharge, delivering 15 m³/h at 10 m head with a 1.1 kW 400V three-phase motor. It handles raw sewage, wastewater and dirty water with solids, for municipal, industrial, mining and building drainage.

Application

• Drainage of wastewater from attenuation tanks, purifying tanks and sewage tanks in water treatment plants.
• Drainage of wastewater containing fibrous additives from leather factories and food processing factories.
• Sewage management, accumulated water, septic tanks and stock farms.
• Pumping sewage from hotels, restaurants, schools and public buildings.

Pump

• High-efficiency anti-clogging enclosed channel impeller
• Flexible installation with hoses, pipes or quick-coupling systems
• Float switch included as standard for single phase models (≤1.1 kW)
• Cable length: 10 m
• Double-end mechanical seal
• Stainless steel welded shaft
• Liquid temperature: 0–40 degC
• Liquid pH value: 4–10
• Max. immersion depth: 10 m

Motor

• Frequency/Pole number: 50 Hz / 2 pole
• Insulation class: F
• Enclosures class: IP68
• Bearing: Ball type

Identification Codes

• SWE - Submersible Sewage Pump with Enclosed Channel Impeller
• First number - Discharge Diameter (mm)
• m - Single Phase Motor (omitted for three-phase)
• Second number - Rated Flow (m³/h)
• Third number - Rated Head (m)
• Fourth number - Rated Power (kW)
• L - Enclosed Channel Impeller feature
