Meudy KBZ47.5 / 7.5KW 400V Submersible Dewatering Pump And Motor
12298
The Meudy KBZ47.5 is a 7.5 kW submersible drainage (dewatering) pump with a 100 mm outlet, built for construction sites, mines, quarries, sewage works and general dewatering. It delivers 48 m³/h at 30 m head, with a maximum head of 40 m and a maximum flow of 84 m³/h.
It has a hard cast iron body, a high chrome alloy semi-open impeller and an IP68 copper-wound motor cooled by the pumped water, with a solids passage of 11.5 mm.
At a glance
Power: 7.5 kW (10 HP)Supply: Three-phase 400 V, 50 HzMax. head: 40 mMax. flow: 84 m³/hConnections: 100 mmBest for: Civil engineering, Mines, quarries, Coal ore & slurries, Sewage treatment plantsSpecifications
| Brand | Meudy |
| Model | KBZ47.5 |
| Pump type | Submersible drainage pump |
| Motor power | 7.5 kW (10 HP) |
| Power supply | Three-phase 400 V, 50 Hz |
| Rated current (400 V) | 15 A |
| Speed | 2850 rpm |
| Starting | Direct on line |
| Outlet | 100 mm |
| Rated duty | 48 m³/h @ 30 m |
| Max. flow | 84 m³/h |
| Max. head | 40 m |
| Solids passage | 11.5 mm |
| Max. liquid temperature | 40 °C |
| Motor protection | IP68 |
| Dimensions (W × L × H) | 36.5 × 80.5 × 39 cm |
| Weight | 114 kg |
| Item code | KBZ47.5(380V) |
Performance Table
| Flow Q (m³/h) | 0 | 20 | 40 | 48 | 60 | 70 | 84 |
|---|---|---|---|---|---|---|---|
| Head H (m) | 40 | 37 | 33.5 | 30 | 26 | 22 | 6 |
Head at each flow rate from the manufacturer's technical data. For a duty-point check use the Get a Quote wizard below.
Performance Curves and Technical Data (PDF)
Download the curve sheet with the performance curves, dimensions and technical data for the Meudy KBZ47.5:
Meudy KBZ KBZE Drainage Pumps Curves
34 kB | Download
Applications
- Civil engineering
- Mines, quarries, Coal ore & slurries
- Sewage treatment plants
- General pumping purposes
Need help choosing or want a price?
Our pump team will check the right size for your flow and head and give you a quote.
WhatsApp us: 082 516 2248 Get a Quote / Size my pump info@pumps.co.za
Frequently Asked Questions
What is the maximum head of the Meudy KBZ47.5?
The Meudy KBZ47.5 has a maximum head of 40 m.
How much water can the Meudy KBZ47.5 pump?
The Meudy KBZ47.5 pumps up to 84 m³/h.
What power supply does the Meudy KBZ47.5 need?
Supply: Three-phase 400 V, 50 Hz. Motor power: 7.5 kW (10 HP).
What are the pipe connections of the Meudy KBZ47.5?
100 mm.
