Leo AP110 / 1.1KW 400V Peripheral Pump And Motor
15622
The LEO AP110 is a 1.1 kW 400V three-phase peripheral pump - the three-phase version of the APm110. Peripheral pumps give high pressure at low flow, ideal for boosting household pressure and small irrigation.
Application
- Can be used to transfer clean water or other liquids similar to water in physical and chemical properties
- Suitable for small living water supply, automatic water sprinkler system, small air conditioner system or supporting equipment etc.
Pump
- Special anti-rust treatment for cast iron pump body and support
- Brass impeller
- AISI 304 shaft
- Max. liquid temperature: +60 degC
- Max. suction: 8 m
Motor
- Low noise&Long life bearing
- Motor with copper winding
- Built-in thermal protector for single phase motor
- Insulation class: F
- Enclosures class: IPX4
- Max. ambient temperature: +50 degC
- IE 2 motor (AP110, AP150)
Identification Codes
- A - LEO Product Style
- P - Peripheral Pump
- m - Single Phase Motor (Omitted for three-phase motor)
- 37 - Power(x10 W)
Performance table
| Flow Q (m³/h) | 0 | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 3 | 3.6 | 4.2 |
| Head H (m) | 85 | 80 | 75 | 65 | 60 | 55 | 50 | 45 | 40 | 30 | 18 | 10 |
Source: LEO APm peripheral pump technical data, 50 Hz.
