AquaDuty AD3/15 / 1.12kW 230V 100mm Submersible Pump & Motor Combination Kit
17045
The AquaDuty AD3/15 is a complete 100 mm (4") submersible borehole pump and motor kit rated at 1.12 kW 230 V.
Applications
- Borehole and well water supply
- Domestic, farm and smallholding water supply
- Irrigation and livestock watering
- Pressure boosting and bulk water transfer
Features
- Pump end, motor and control box supplied as a matched set
- 50 m submersible cable and 50 m safety rope included
- Polyurethane baseplate and 32 mm compression adaptors included
- Built-in non-return valve in the 1¼" outlet
Kit Includes
- Submersible pump end and motor
- Control box
- 50 m submersible cable
- 50 m safety rope
- Polyurethane baseplate
- 2 x 32 mm x 1¼" compression male adaptors
Specifications
| Parameter | Value |
|---|---|
| Brand | AquaDuty |
| Item code | 830008930 |
| Model | AD3/15 |
| Type | Submersible borehole pump and motor kit |
| Motor power | 1.12 kW |
| Supply voltage | 230 V single-phase |
| Outlet | 1¼" (32 mm) BSP female |
| Borehole diameter | 100 mm (4") and larger |
