Wilo Vario Boost CO-2 Medana CH1-L 603-MT Pressure Booster Set – 230V (VSD)
19145
The Wilo Vario Boost CO-2 Medana CH1-L 603-MT is a variable-speed pressure boosting system from the Wilo Vario Boost Medana MT range. Pressure-boosting system with two or three non-selfpriming stainless steel high-pressure multistage centrifugal pumps switched in parallel. Supplied as a factory-assembled set with 2 pump(s).
At a glance
Max. head: 35.6 mMax. flow: 20 m³/hSupply: 230 V single-phaseSpecifications
| Brand | Wilo |
| Item code | 2805111A |
| Model | Vario Boost CO-2 Medana CH1-L 603-MT |
| Supply | 230 V single-phase |
| Series | Wilo Vario Boost Medana MT |
| Type | variable-speed pressure boosting system |
| Number of pumps | 2 |
Performance Table
| Flow (m³/h) | 1.21 | 2.5 | 5 | 7.5 | 10 | 12.5 | 15 | 17.5 | 20 |
|---|---|---|---|---|---|---|---|---|---|
| Head (m) | 35.6 | 35.3 | 34.6 | 33.4 | 31.7 | 29.1 | 25.5 | 20.4 | 13.5 |
| Shaft power P2 (kW) | 0.9 | 1.02 | 1.23 | 1.44 | 1.62 | 1.78 | 1.88 | 1.91 | 1.89 |
| Hydraulic efficiency (%) | 16 | 27 | 42 | 51 | 56 | 59 | 59 | 54 | 40 |
| NPSH required (m) | 2.39 | 2.99 | 2.67 | 1.71 | 1.22 | 1.72 | 3.53 | 6.4 | 9.93 |
Head at each flow rate from the manufacturer's technical data. For a duty-point check use the Get a Quote wizard below.
Performance Curves and Technical Data (PDF)
Download the curve sheet with the performance curves, dimensions and technical data for the Wilo Vario Boost CO-2 Medana CH1-L 603-MT Pressure Booster Set (VSD):
Wilo Medana CH1-L 603 Performance Curve (50 Hz)
29 kB | Download
Applications
- Fully automatic water supply and pressure boosting in inlet mode, either from the public water supply network or from a tank, for domestic, commercial, industrial and municipal applications (e.g. residential, office, administration buildings, hotels, hospitals, trades, industry, water supply companies)
- Pumping drinking water, process water, cooling water or other industrial water, which does not affect the materials used, neither chemically nor mechanically, and does not have any abrasive or long-fibre constituents
Features
- High operational reliability, thanks to system with one, two or three horizontal multistage CH1-L pumps with stainless steel hydraulics
- Easy installation and maintenance thanks to special, flexibly adjustable connections to manifolds
- Easy commissioning and operation with the Easy Controller
- Drinking water approval (ACS and KTW) for pumps with components made of stainless steel that come into contact with the fluid
Need help choosing or want a price?
Our pump team will check the right size for your flow and head and give you a quote.
WhatsApp us: 082 516 2248 Get a Quote / Size my pump info@pumps.co.za
Frequently Asked Questions
What is the maximum head of the Wilo Vario Boost CO-2 Medana CH1-L 603-MT Pressure Booster Set (VSD)?
The Wilo Vario Boost CO-2 Medana CH1-L 603-MT Pressure Booster Set (VSD) has a maximum head of 35.6 m.
How much water can the Wilo Vario Boost CO-2 Medana CH1-L 603-MT Pressure Booster Set (VSD) pump?
The Wilo Vario Boost CO-2 Medana CH1-L 603-MT Pressure Booster Set (VSD) pumps up to 20 m³/h.
