Leo AMS210-0.75 / 0.75KW 400V Centrifugal Pump And Motor
15555
Introducing the LEO AMS(m)120/,75, a robust stainless steel centrifugal pump engineered for versatile residential and commercial water applications. This single-phase motor pump excels in household water supply, garden watering, greenhouse irrigation, fish farming, and industrial water circulation systems, making it an ideal choice for anyone seeking reliable pressure boosting and water distribution across diverse settings.
Built with durable AISI 304 stainless steel construction throughout its pump body and shaft, the AMS(m)120/1.1 delivers corrosion resistance and longevity even in demanding environments. Equipped with an energy-efficient IE2 motor featuring low-noise operation, long-life bearings, and built-in thermal protection, this pump handles maximum operating pressures of 4.5 bar and liquid temperatures up to 85 degC, making it perfectly suited for central heating systems, high-rise building water supply, and centralized air conditioning circulation.
At a glance
Power: 0.75 kW (1 HP)Supply: 400 V three-phase, 50 HzMax. head: 16.8 mMax. flow: 18 m³/h (300 l/min)Connections: 1 1/2" / 1 1/4"Specifications
| Brand | Leo |
| Model | AMS210-0.75 |
| Type | AMSm/AMS Stainless Steel Centrifugal Pump (210/370) |
| Motor power | 0.75 kW (1 HP) |
| Supply | 400 V three-phase, 50 Hz |
| Inlet / outlet | 1 1/2" / 1 1/4" |
| Shut-off head | 16.8 m |
| Flow range | 0 – 18 m³/h (0 – 300 l/min) |
| Dimensions (W × L × H) | 24 × 41 × 27 cm |
| Weight | 15 kg |
| Item code | AMS210-0.75(380V) |
Performance Table
| Flow Q (m³/h) | 0 | 7.2 | 8.4 | 9.6 | 10.8 | 12 | 15 | 18 |
|---|---|---|---|---|---|---|---|---|
| Flow Q (l/min) | 0 | 120 | 140 | 160 | 180 | 200 | 250 | 300 |
| Head H (m) | 16.8 | 15.6 | 15.2 | 14.8 | 14.2 | 13.6 | 11.9 | 9.8 |
Head at each flow rate from the manufacturer's technical data. For a duty-point check use the Get a Quote wizard below.
Performance Curves and Technical Data (PDF)
Download the curve sheet with the performance curves, dimensions and technical data for the Leo AMS210-0.75:
Leo AMSm/AMS Stainless Steel Centrifugal Pump (210/370) – Performance Curves and Technical Data (01-DOMESTIC PUMP catalogue p40)
356 kB | Download
Applications
It is applicable to household water supply, equipment support, pipeline pressurization, garden watering, vegetable greenhouse watering, fish farming and poultry raising, industrial and mining, water supply and drainage of enterprises and high-rise buildings, central air conditioner and centralized heating circulation system, etc.
Pump
- AISI 304 pump body
- AISI 304 shaft
- Max. operating pressure: 4.5 bar
- Max.liquid temperature: +85 degC
- Altitude: up to 1000 m
Motor
- IE2 motor
- Low noise&Long life bearing
- Motor with copper winding
- Built-in thermal protector for single phase motor
- Insulation class: F
- Enclosures class: IPX4
- Max. ambient temperture: +40 degC
Model Code: AMS210-0.75(380V)
- A - LEO Product Style
- MS - Stainless Steel Centrifugal Pump
- m - Single Phase Motor (Omitted for three-phase motor)
- 70 - Rated Flow (l/min)
- 0.37 - Rated Power (kW)
Need help choosing or want a price?
Our pump team will check the right size for your flow and head and give you a quote.
WhatsApp us: 082 516 2248 Get a Quote / Size my pump info@pumps.co.za
Frequently Asked Questions
What is the maximum head of the Leo AMS210-0.75?
The Leo AMS210-0.75 has a maximum head of 16.8 m.
How much water can the Leo AMS210-0.75 pump?
The Leo AMS210-0.75 pumps up to 18 m³/h (300 l/min).
What power supply does the Leo AMS210-0.75 need?
Supply: 400 V three-phase, 50 Hz. Motor power: 0.75 kW (1 HP).
What are the pipe connections of the Leo AMS210-0.75?
1 1/2" / 1 1/4".
